Chapter 3: System operation
142 E-FSA64 and E-FSA250 Technical Reference Manual
Figure 48: LCD under off-normal conditions
00:00:00 A001 D001
001 Alarm Active
Computer room closet
Floor 1
Time
Active points
Disabled
points
Event
number
Event type
message
Device
label
Event details display screens
The off-normal events that take place in the system contain event information
that is displayed on the LCD screen. Additional information is available on a
secondary screen. The screen displays the following information based on the
type of event that takes place:
• Loop number: The loop the device is on
• Device number: The device address (number)
• Device type: The device type that was assigned in programming
• Internal event number: See “Event ID numbers and descriptions” on page 154
• Zone number and device label for devices in zones
• Annunciator number and label
• Other information when it is available
Figure 49: Device event details display screen
Loop 1 Device 001
Smoke
Loop
number
Device
number
Device
type
