Page 47

SA-1100 Developer’s Manual

5-3

Coprocessors

5.2.2

Register 1 – Control

Register 1 is a read/write register containing control bits. All writable bits in this register are forced
low by reset. The shaded bits (also labeled r) are reserved and are not readable or writable.

M bit 0

Enable/disable

0 – On-chip memory-management unit disabled

1 – On-chip memory-management unit enabled

A bit 1

Address fault enable/disable

0 – Alignment fault disabled

1 – Alignment fault enabled

C bit 2

Data cache enable/disable

0 – Data cache disabled

1 – Data cache enabled

W bit 3

Write buffer enable/disable

0 – Write buffer disabled

1 – Write buffer enabled

B bit 7

Big/little endian

0 – Little endian operation

1 – Big endian operation

S bit 8

System

This bit selects the access checks performed by the memory-management unit.

See the

ARM Architecture Reference for more information.

R bit 9

ROM

This bit selects the access checks performed by the memory-management unit.

See the

ARM Architecture Reference for more information.

I bit 12

Instruction cache enable/disable

0 – Instruction cache disabled

1 – Instruction cache enabled

X bit 13

Virtual interrupt vector adjust

0 – Base address of interrupt vectors is 0h0000 0000

1 – Base address of interrupt vectors is 0hFFFF 0000

Bits 14..31

Unused.

Undefined on Read. Writes ignored.

r X

R S B 1 1

1 W
