Pcmcia memory or i/o 16-bit access -32, Figure 10-15 – Intel STRONGARM SA-1100 User Manual
Page 146
10-32
SA-1100
Developer’s Manual
Memory and PCMCIA Control Module
Figure 10-15. PCMCIA Memory or I/O 16-Bit Access
A4788-01
CPU Clock
Memory Clock
BS_xx+1
BS_xx = 1
BS_xx+2
BS_xx+1
3*(BS_xx+1)
3*(BS_xxL+1)
BCLK
nPCE2, nPCE1
A, nPREG,
PSKTSEL
nPWE, nPIOW,
nPOE, or nPIOR
nPWAIT
Latch Read
Data
Read Data
[15:0]
Write Data
[15:0]
nIOIS16
(for I/O only)
