12-2 SA-1100 Developer’s Manual
DC Parameters
12.2 DC Operating Conditions
Table 12-2 lists the functional operating dc parameters for the SA-1100.
Table 12-2. SA-1100 DC Operating Conditions
Symbol Parameter Min Nom Max Units Notes
Vihc † IC input high voltage 0.8 × VDDX — VDDX V 1, 2
Vilc † IC input low voltage 0.0 — 0.2
×
VDDX V 1, 2
Vohc OCZ output high voltage 0.8 × VDDX — VDDX V 1, 3
Volc OCZ output low voltage 0.0 — 0.2 × VDDX V 1, 3
Iohc High-level output current — — – 2 mA —
Iolc Low-level output current — — 2 mA —
Ta Ambient operating temperature 0 — 70 °C —
Iin IC input leakage current — 10 — µA —
Ioh
Output high current
(Vout = VDD – 0.4 V)
— 2 — mA —
Iol
Output high current
(Vout = VSS + 0.4 V)
— 2 — mA —
Cin Input capacitance — 5 — pF 4
ESD HBM model ESD — 1 — KV —
NOTES:
1. Voltages measured with respect to VSS.
2. IC – CMOS-level inputs (includes IC and ICOCZ pin types).
3. OCZ – Output, CMOS levels, tristateable.
4. Parameter guaranteed by design
† Not tested at this time
