9-32

SA-1100

Developer’s Manual

System Control Module

9.5.6

Pin Operation in Sleep Mode

The SA-1100 pins are categorized by the following types based on their behavior during sleep mode:

Type 1 – These pins are outputs and are driven low during sleep. These pins hold their state after
sleep mode is exited until the DRAM_control_hold bit in the PSSR is cleared.

Type 2 – These pins are outputs and are normally driven to a one in sleep. To support systems that
power down external devices, these pins can also be tristated in sleep through the use of the
FLOAT_STATIC and FLOAT_PCMCIA bits in the PCFR. See the

Section 9.5, “Power Manager”

on page 9-26

.

Type 3 – These pins are I/Os. When programmed as outputs, they can be actively held high or low
during sleep. When programmed as inputs, they are actively sampled by the SA-1100.

Type 4 – These pins are I/Os but become inputs during sleep. They can be programmed to hold the pin
state at a zero or can be tristated. The receivers on these pins are disabled during sleep. These pins hold
their state after sleep mode is exited until the peripheral_control_hold bit in the PSSR is cleared.

Type 5 – These pins are outputs and are actively driven during sleep.

Type 6 – These pins are outputs and are tristated during sleep.

Type 7 – These pins are inputs and are actively sampled during sleep.

Type 8 – These pins are inputs and are not observed during sleep; the receiver is disabled.

Type 9 – These pins are analog inputs and outputs, and are always active.

Table 9-3.

Pin State During Step

Pin Name

Type

Pin Name

Type

Pin Name

Type

Pin Name

Type

A<25:0>

1

nPREG

1

RXD_2

4

nRESET_OUT

1

D<31:0>

1

L_DD<7:0>

4

TXD_3

4

nTRST

8

nCS<3:0>

2

L_FCLK

4

RXD_3

4

TDI

8

nOE

2

L_BIAS

4

GP<27:0>

3 TDO

6

nWE

2

TXD_C

4

ROM_SEL

8

TMS

8

nRAS<3:0>

1

RXD_C

4

PXTAL

9

TCK

8

nCAS<3:0>

1

SCLK_C

4

PEXTAL

9

TCK_BYP

7

nPIOW

2

SFRM_C

4

TXTAL

9

TESTCLK

7

nPIOR

2

UDC+

4

TEXTAL

9

VDD

nPCE<2:1>

2

UDC-

4

PWR_EN

5

VDDX

nIOIS16

2

TXD_1

4

BATT_FAULT

7

VSS

nPWAIT

2

RXD_1

4

VDD_FAULT

7

VSSX

PSKTSEL

1

TXD_2

4

nRESET

7
