SA-1100 Developer’s Manual 9-35
System Control Module
9.5.7.3 Power Manager PLL Configuration Register (PPCR)
The PPCR contains bits used to configure the core operating frequency generated by the PLL. The
following table shows the bit-field definitions for this register. See
Chapter 8, “Clocks” for the
frequencies generated through settings in this register. Note that the contents of this register are
preserved during sleep mode and do not need to be re-initialized after a wake-up event. The PPCR
is only cleared upon the assertion of nRESET (hard reset).
Bit 31 30 29 28 27 26 25 24 23 22 21 20 19 18 17 16
R/W Reserved
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1 0
R/W Reserved
CCF
4
CCF
3
CCF
2
CCF
1
CCF
0
Reset 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0 0
Bit Name Description
4-0 CCF<4:0> Clock speed configuration.
See Chapter 8, “Clocks” for the values in this field.
31..5 — Reserved.
