11-14 SA-1100 Developer’s Manual
Peripheral Control Module
11.6.3 DMA Register List
The following table lists the registers contained within the DMA controller:
Physical Address Register Name Symbol
Channel 0 Registers
0h B000 0000 DMA device address register. DDAR0
0h B000 0004
DMA control/status register 0.
Write ones to set.
DCSR0
0h B000 0008 Write ones to clear.
0h B000 000C Read only.
0h B000 0010 DMA buffer A start address 0. DBSA0
0h B000 0014 DMA buffer A transfer count 0. DBTA0
0h B000 0018 DMA buffer B start address 0. DBSB0
0h B000 001C DMA buffer B transfer count 0. DBTB0
Channel 1 Registers
0h B000 0020 DMA device address register 1. DDAR1
0h B000 0024
DMA control/status register 1.
Write ones to set.
DCSR1
0h B000 0028 Write ones to clear.
0h B000 002C Read only.
0h B000 0030 DMA buffer A start address 1. DBSA1
0h B000 0034 DMA buffer A transfer count 1. DBTA1
0h B000 0038 DMA buffer B start address 1. DBSB1
0h B000 003C DMA buffer B transfer count 1. DBTB1
Channel 2 Registers
0h B000 0040 DMA device address register 2 DDAR2
0h B000 0044
DMA control/status register 2.
Write ones to set.
DCSR2
0h B000 0048 Write ones to clear.
0h B000 004C Read only.
0h B000 0050 DMA buffer A start address 2. DBSA2
0h B000 0054 DMA buffer A transfer count 2. DBTA2
0h B000 0058 DMA buffer B start address 2. DBSB2
0h B000 005C DMA buffer B transfer count 2. DBTB2
Channel 3 Registers
0h B000 0060 DMA device address register 3. DDAR3
0h B000 0064
DMA control/status register 3.
Write ones to set.
DCSR3
0h B000 0068 Write ones to clear.
0h B000 006C Read only.
