Delivering Essential Features and Leading Technologies
The Intel ® Desktop Boards D845GLAD and D845GLLY deliver integrated graphics solutions
with essential features that support Intel ® Pentium ® 4 and Intel ® Celeron ® processors with
400-MHz system bus in the mPGA478-pin package. Featuring the Intel ® 845GL chipset with
support for up to 2GB** of DDR266** or PC133** SDRAM memory, these boards deliver
remarkable value and flexibility with four PCI slots, Hi-Speed USB 2.0*** and optional
integrated LAN.
In line with Intel’s reputation for proven reliability and leading technology, Intel ® Desktop Boards
D845GLAD and D845GLLY undergo extensive compatibility testing and deliver exciting new
features such as Hi-Speed USB 2.0*** and integrated Intel ® Extreme Graphics.
Low Cost Solution
Desktop Boards D845GLAD and D845GLLY were designed with a high level of integration to
minimize overall system cost. The new integrated Intel ® Extreme Graphics and the SigmaTel*
AC’97 Audio solution eliminate the need for costly discrete Video and Audio PCI cards by deliv-
ering high quality video and audio solutions. With 4 PCI slots these boards offer remarkable
flexibility and the advantage of the lower system costs associated with microATX solutions.
Intel ® Desktop Boards D845GLAD and D845GLLY
for Intel ® Celeron ® processors in the mPGA478-pin packages
Intel ® Extreme Graphics
