Servo control
3.7 Current setpoint filter
Drive Functions
80
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
Table 3-2 Example of a PT2 filter
STARTER filter parameters Amplitude log frequency curve Phase frequency curve
Characteristic frequency f
N
500 Hz
Damping D
N
0.7 dB
I
1
+]
G%
Band-stop with infinite notch depth
Table 3-3 Example of band-stop with infinite notch depth
STARTER filter parameters Amplitude log frequency curve Phase frequency curve
Blocking frequency f
Sp
= 500 Hz
Bandwidth (-3 dB) f
BB
= 500 Hz
Notch depth K = -∞ dB
Reduction Abs = 0 dB
I
%%
+]
I +]
Simplified conversion to parameters for general order filters:
Reduction or increase after the blocking frequency (Abs)
Infinite notch depth at the blocking frequency
● Numerator frequency f
Z
= f
Sp
● Numerator damping D
Z
= 0
● Denominator natural frequency f
N
= f
Sp
● Denominator damping
6S
%%
1
I
I
'
