Basic information about the drive system
12.10 Rules for wiring with DRIVE-CLiQ
Drive Functions
510
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
12.10.2 Rules for different firmware releases
Rules for FW2.1
● Only one Active Line Module can be connected to a Control Unit.
● The default sampling times must not be changed.
● A Double Motor Module must not be operated as a single drive.
● Mixed operation of servo and vector V/f is not permitted.
● The Active Line Module and the Motor Modules must be connected to separate DRIVE-
CLiQ lines, both for vector and for servo.
Table 12-16 Maximum number of drives that can be controlled by a Control Unit 320
Servo Vector
Number of components 1 Active Line Module +
6 Motor Modules
1 Active Line Module +
2 Motor Modules
(scanning frequency of current controller
250 µs /
speed controller 1000 µs)
Note:
In addition, the "Safe Standstill" function can be activated and a TM31 connected.
Rules for FW2.2
● Only one Active Line Module can be connected to a Control Unit.
● The default sampling times must not be changed.
● A Double Motor Module must not be operated as a single drive.
Table 12-17 Maximum number of drives that can be controlled by a Control Unit 320
Servo Vector V/f (=vector
without speed control
function module)
Vector
1 Active Line Module +
6 Motor Modules
1 Active Line Module +
4 Motor Modules
(sampling time of current
controller 250 µs)
1 Active Line Module +
6 Motor Modules
(sampling time of current
controller 400 µs)
Number of
components
Servo and vector V/f:
1 Active Line Module + 5 Motor Modules
(servo: Current controller 125 µs / speed controller
125 µs vector V/f:
sampling time of current controller 250 µs with max.
2 V/f drives. Sampling time of current controller 400 µs
with more than 2 V/f drives)
1 Active Line Module +
2 Motor Modules
(sampling time of current
controller 250 µs / speed
controller 1000 µs)
1 Active Line Module +
4 Motor Modules
(sampling time of current
controller 400 µs / speed
controller 1600 µs)
