Communication PROFIBUS DP/PROFINET IO
10.1 Communications according to PROFIdrive
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
369
Bit Meaning Comments BICO
4 DDS eff., bit 4 – BO: r0051.4
5, 6 Reserved – – –
1 Axis parking active 7 Parking axis
0 Axis parking not active
BO: r0896.0
1 Travel to fixed endstop 8 Travel to fixed endstop
0 No travel to fixed stop
BO: r1406.8
9, 10 Reserved – – –
1 Data record changeover active 11 Data set changeover
0 No data set changeover active
BO: r0835.0
12 Drive unit sign-of-life bit 0 – User data integrity (4-bit counter) Implicitly
interconnected
13 Drive unit sign-of-life bit 1 –
14 Drive unit sign-of-life bit 2 –
15 Drive unit sign-of-life bit 3 –
NACT_A (Speed setpoint A (16 bit))
● Actual speed value with 16-bit resolution.
● The speed actual value is normalized in the same way as the setpoint (see NSOLL_A).
NACT_B (Speed setpoint B (32 bit))
● Actual speed value with 32-bit resolution.
● The speed actual value is normalized in the same way as the setpoint (see NSOLL_B).
Gn_ZSW (encoder n status word)
Gn_XIST1 (encoder n position actual value 1)
Gn_XIST2 (encoder n position actual value 2)
This process data belongs to the encoder interface.
ITIST_GLATT
The actual current value smoothed with p0045 is displayed.
MELDW (message word)
See function diagram [2456]
Table 10-14 Description of MELDW (message word)
Bit Meaning Comments BICO
0 Ramp-up/ramp-down completed /
ramp-function generator active
1 Ramp-up/ramp-down completed.
•
The ramp-up procedure is completed once the
speed setpoint has been changed.
BO: r2199.5
