Infeed
1.2 Smart Infeed
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
31
Overview: key parameters
● p3624 Infeed harmonics controller order
● p3625 Infeed harmonics controller scaling
● r0069[0..6] Phase current, actual value
1.2 Smart Infeed
1.2.1 Smart Infeed closed-loop control
General
Note
Line Modules (Active Line Modules, Basic Line Modules, Smart Line Modules) of different
types must not be operated simultaneously on the same DC link.
Features
● For Smart Line Modules with a power of ≥ 16 kW
● Unregulated DC link voltage
● Regenerative feedback capability
Description
The firmware for the Smart Line Modules is on the Control Unit assigned to it. The Smart
Line Module and Control Unit communicate via DRIVE-CLiQ.
