Basic information about the drive system
12.12 System sampling times
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
525
p0112 p0115[0] p0115[1] p0115[2] p0115[3] p0115[4] p0115[5] p0115[6]
2: Low 250 - - 2000 - - -
3: Standard 250 - - 2000 - - -
4: High 250 - - 1000 - - -
5: xHigh - - - - - - -
Table 12-24 For Basic Infeed Booksize, the sampling time is set using p0112
p0112 p0115[0] p0115[1] p0115[2] p0115[3] p0115[4] p0115[5] p0115[6]
1: xLow - - - - - - -
2: Low - - - - - - -
3: Standard - - - - - - -
4: High 250 - - 2000 - - -
5: xHigh - - - - - - -
Table 12-25 For Basic Infeed Chassis, the sampling time is set using p0112
p0112 p0115[0] p0115[1] p0115[2] p0115[3] p0115[4] p0115[5] p0115[6]
1: xLow 2000 - - 2000 - - -
2: Low 2000 - - 2000 - - -
3: Standard 2000 - - 2000 - - -
4: High 250 - - 2000 - - -
5: xHigh - - - - - - -
Table 12-26 For Servo, the sampling time is set using p0112
p0112 p0115[0] p0115[1] p0115[2] p0115[3] p0115[4] p0115[5] p0115[6]
1: xLow 250 250 250 4000 2000 8000 4000
2: Low 125 250 250 4000 2000 8000 4000
3: Standard 125 125 125 4000 1000 4000 4000
4: High 62.5 62.5 62.5 1000 1000 2000 1000
5: xHigh - - - - - - -
Table 12-27 For Vector, the sampling time is set using p0112 (p0112 = 1 not for p0092 = 1 and not for PM340)
p0112 p0115[0] p0115[1] p0115[2] p0115[3] p0115[4] p0115[5] p0115[6]
1: xLow 400 1600 1600 3200 3200 3200 3200
2: Low 250 1000 2000 1000 2000 4000 4000
3: Standard 250 1000 1000 1000 2000 4000 4000
4: High 250 500 1000 500 1000 2000 2000
5: xHigh 250 250 1000 250 1000 2000 1000
