Communication PROFIBUS DP/PROFINET IO
10.3 Communications via PROFINET IO
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
437
10.3 Communications via PROFINET IO
10.3.1 General information about PROFINET IO
10.3.1.1 General information about PROFINET IO for SINAMICS
General information
PROFINET IO is an open Industrial Ethernet standard for a wide range of production and
process automation applications. PROFINET IO is based on Industrial Ethernet and
observes TCP/IP and IT standards.
The following standards ensure open, multi-vendor systems:
● International standard IEC 61158
PROFINET IO is optimized for high-speed, time-critical data communication at field level.
PROFINET
Within the framework of Totally Integrated Automation (TIA), PROFINET represents a
consequent enhancement of:
● PROFIBUS DP, the established field bus,
and
● Industrial Ethernet, the communication bus for the cell level.
Experience gained from both systems was and is being integrated into PROFINET. As an
Ethernet-based automation standard defined by PROFIBUS International (PROFIBUS user
organization), PROFINET is a manufacturer-independent communication and engineering
model.
When a CBE20 is inserted, SINAMICS S120 becomes an IO device in the sense of
PROFINET. With SINAMICS S120 and CBE20, communications can either be established
via PROFINET IO with IRT or via PROFINET IO with RT. Mixed operation is not supported.
Note
PROFINET for drive technology is standardized and described in the following document:
References:
/P5/ PROFIdrive Profile Drive Technology
PROFINET System Description,
Order no. 6ES7398-8FA10-8AA0, 6ES7151-1AA10-8AA0
CAUTION
The cyclic PZD channel for PROFIBUS DP is deactivated when the CBE20 is plugged in
