Basic information about the drive system
12.12 System sampling times
Drive Functions
528
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
This rule also applies for parallel connection (3 or 4 Motor Modules connected in parallel)
18. For 4 vector drives (speed control: r0108.2 = 1), a minimum current controller sampling
time of 400.0 µs can be set
(400.0 µs ≤ p0115[0] ≤ 500 µs).
19. When servo is operated together with vector-V/f, a maximum of 5 DOs is possible (ALM,
TB and TM additionally possible):
Examples:
– 1 servo + 4 vector-V/f (vector-V/f: 400 µs ≤ p0115[0] ≤ 500 µs)
– 2 servo + 3 vector-V/f (vector-V/f: 400 µs ≤ p0115[0] ≤ 500 µs)
– 3 servo + 2 vector-V/f (vector-V/f: 250 µs ≤ p0115[0] ≤ 500 µs)
– 4 servo + 1 vector-V/f (vector-V/f: 250 µs ≤ p0115[0] ≤ 500 µs)
20. A maximum of two DRIVE-CLiQ lines are possible in the unit where the lowest sampling
times are not integer multiples of one another.
Example 1:
At CU-X100: ALM with 250 µs
At CU-X101: 1 vector drive object with 455 µs (p0113=1.098 kHz)
This setting is allowed.
Other DQS must have minimum sampling time of 250 µs or 455 µs.
12.12.4 Default settings for the sampling times
When commissioning for the first time, the current controller sampling times (p0115[0]) are
automatically pre-set with these default values as follows:
Table 12-28 Default settings
Construction type Number p0112 p0115[0] p1800
Active Infeed and Smart Infeed
Booksize
1 2 (Low) 250 µs -
Chassis
400 V / ≤ 300 kW
690 V / ≤ 330 kW
1 2 (Low) 250 µs -
Chassis
400 V / > 300 kW
690 V / > 330 kW
1 0 (Expert)
1 (xLow)
375 µs (p0092 = 1)
400 µs (p0092 = 0)
-
-
Basic Infeed
Booksize
1 3 (High) 250 µs -
Chassis 1 3 (Standard) 2000 µs -
Servo
Booksize
1 to 6 3 (Standard) 125 µs 4 kHz
Chassis 1 to 6 1 (xLow) 250 µs 2 kHz
Blocksize 1 to 5 3 (Standard) 125 µs 4 kHz
Vector
