Communication PROFIBUS DP/PROFINET IO
10.1 Communications according to PROFIdrive
Drive Functions
386
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
Bit Meaning Remarks BICO
1 Digital input/output 9
(DI/DO 9)
– DI/DO 9 on the Control Unit must be parameterized as an output
(p0728.9 = 1).
BI: p0739
2 Digital input/output 10
(DI/DO 10)
– DI/DO 10 on the Control Unit must be parameterized as an output
(p0728.10 = 1).
BI: p0740
3 Digital input/output 11
(DI/DO 11)
– DI/DO 11 on the Control Unit must be parameterized as an output
(p0728.11 = 1).
BI: p0741
4 Digital input/output 12
(DI/DO 12)
– DI/DO 12 on the Control Unit must be parameterized as an output
(p0728.12 = 1).
BI: p0742
5 Digital input/output 13
(DI/DO 13)
– DI/DO 13 on the Control Unit must be parameterized as an output
(p0728.13 = 1).
BI: p0743
6 Digital input/output 14
(DI/DO 14)
– DI/DO 14 on the Control Unit must be parameterized as an output
(p0728.14 = 1).
BI: p0744
7 Digital input/output 15
(DI/DO 15)
– DI/DO 15 on the Control Unit must be parameterized as an output
(p0728.15 = 1).
BI: p0745
8...
15
Reserved – – –
Note:
The bidirectional digital inputs/outputs (DI/DO) can be connected as either an input or an output (see also transmit signal
E_DIGITAL).
MT_STW
Control word for the "central probe" function. Display via r0685.
Table 10-23 Description of MT_STW (control word for Control Unit)
Bit Meaning Remarks BICO
0 Falling edge probe 1 –
1 Falling edge probe 2 –
2 Falling edge probe 3 –
3 Falling edge probe 4 –
4 Falling edge probe 5 –
5 Falling edge probe 6 –
Activation of measuring time determination with the next falling
edge
For telegram 392, in addition, probes 3 and 6
6...7 Reserved – –
8 Rising edge probe 1 –
9 Rising edge probe 2 –
10 Rising edge probe 3 –
11 Rising edge probe 4 –
12 Rising edge probe 5 –
13 Rising edge probe 6 –
Activation of measuring time determination with the next rising edge
For telegram 392, in addition, probes 3 and 6
14...
15
Reserved – –
CI: p0682
CU_ZSW (status word for Control Unit, CU)
See function diagram [2458]
