Basic information about the drive system
12.12 System sampling times
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
529
Construction type Number p0112 p0115[0] p1800
Booksize 4 kHz
Chassis
400 V / ≤ 250 kW
1 to 2 only n_ctrl
1 to 4 only V/f
1 to 2 n_ctrl and
V/f mixed
3 (Standard) 250 µs
2 kHz
Booksize 4 kHz
Chassis
400 V / ≤ 250 kW
3 to 4 only n_ctrl
5 to 6 only V/f
3 to 4 n_ctrl and
V/f mixed
0 (Expert) 500 µs
2 kHz
1 to 3 only n_ctrl
1 to 6 only V/f
1 to 3 n_ctrl and
V/f mixed
0 (Expert)
1 (xLow)
375 µs (p0092 = 1)
400 µs (p0092 = 0)
1.333 kHz
1.25 kHz
Chassis
> 250 kW
690 V
4 only n_ctrl
4 n_ctrl and V/f
mixed
0 (Expert)
1 (xlow)
500 µs (p0092 = 1)
400 µs (p0092 = 0)
2 kHz
1.25 kHz
Booksize 4 kHz
Chassis
> 6 only V/f 0 (Expert) 500 µs
2 kHz
1 to 2 only n_ctrl
1 to 4 only V/f
3 (Standard) 250 µs 4 kHz Blocksize
> 2 n_ctrl (min. 1)
> 4 only V/f
0 (Expert) 500 µs 4 kHz
Caution
If a Power Module Blocksize is connected to a Control Unit, the sampling times of all vector drives are set according to the
rules for Power Modules Blocksize (only 250 µs or 500 µs possible).
12.12.5 Examples when changing sampling times / pulse frequencies
Example: Changing the current controller sampling time from 62.5 µs with p0112
Preconditions:
● Maximum 2 drives, Booksize format
● Servo motor control type
Procedure:
1. p0009 = 3 (not for offline operation)
2. Switch to the first servo drive object
3. p0112 = 4
4. Switch to the second servo drive object and repeat step 3.
5. p0009 = 0 (not for offline operation)
6. When STARTER is in offline mode: Download into the drive.
