Basic functions

6.16 Updating the firmware

Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4

217

6.16

Updating the firmware

The software must be updated if extended functions are made available in a more recent

version and these functions are to be used.
The software for the SINAMICS drive system is distributed in the system. Firmware is

installed on each individual DRIVE-CLiQ component and the Control Unit.
The Control Unit receives its software automatically from the CF card during startup, which

means that it does not need to be updated separately; you simply have to exchange the CF

card with a new one containing the latest software version.
When the firmware is updated, the software is saved in a non-volatile manner in the DRIVE-

CLiQ component. The firmware of the DRIVE-CLiQ components is also on the CF card and,

by means of the factory setting p7826 = 1, it is automatically copied to the DRIVE-CLiQ

components when the CF card is first installed (from FW 2.5).
After project download or automatic configuration, a firmware update is started on all

connected DRIVE-CLiQ components. This upgrades all DRIVE-CLiQ components to the

firmware release that matches the CF card.
This may take a few minutes, and is indicated by the green/red flashing of the READY-LED

of the relevant component and by the orange blinking (0.5 Hz) of the Control Unit.
Parameter p7827 indicates the progress.
When all updates have run, the READY-LED of the Control Unit flashes orange at 2 Hz and

the READY-LED of the relevant component flashes green/red at 2 Hz. For the firmware to be

activated, a POWER ON must be carried out for the components.
For individual components, STARTER dialogs (drive unit -> configuration -> version

overview) can serve to read out the firmware version or to start the firmware update for

individual components manually.

Note
The versions of the DRIVE-CLiQ components and that of the Control Unit can differ. An

overview of the versions is provided on the CF card in the file "content.txt" or can be read out

via the parameter r7825.
