Safety Integrated basic functions

9.8 Acceptance test and certificate

Drive Functions

326

Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4

Scope of a complete acceptance test

Documentation

Machine documentation (including the SI functions)
1. Machine description and overview diagram
2. SI functions for each drive
3. Description of safety equipment

Functional test

Check the individual SI functions used
1. "Safe torque off" function, part 1
2. "Safe torque off" function, part 2
3. "Safe Stop 1" function
4. "Safe brake control" function

Completion of certificate

Record the commissioning procedure and provide countersignatures.
1. Check the Safety parameters
2. Record the checksums
3. Verify the data backups
4. Countersignatures

Appendix

Measurement records for function test parts 1 and 2.
● Alarm logs
● Trace recordings

9.8.2

Documentation

Table 9-6

Machine description and overview diagram

Designation

Type

Serial number

Manufacturer

End customer

Electrical axes
