Communication PROFIBUS DP/PROFINET IO
10.1 Communications according to PROFIdrive
Drive Functions
Function Manual, (FH1), 07/2007 Edition, 6SL3097-2AB00-0BP4
403
Parameter request Offset
Subindex = 0 dec 26
Attribute = 10 hex No. of elements = 01 hex 22 + 23
Parameter no. = 1059 dec 24
4. parameter address
Subindex = 0 dec 26
Attribute = 10 hex No. of elements = 01 hex 22 + 23
Parameter no. = 1059 dec 24
4. parameter address
Subindex = 0 dec 26
Format = 07 hex No. of values = 01 hex 28 + 29
Value = 02D2 hex 30
1. parameter value(s)
Value = 0404 hex 32
Format = 07 hex No. of values = 01 hex 34 + 35
Value = 02D2 hex 36
2. parameter value(s)
Value = 0405 hex 38
Format = 08 hex No. of values = 01 hex 40 + 41
Value = 4396 hex 42
3. parameter value(s)
Value = 0000 hex 44
Format = 08 hex No. of values = 01 hex 46 + 47
Value = 4416 hex 48
4. parameter value(s)
Value = 0000 hex 50
Information about the parameter request:
● Request reference:
The value is selected at random from the valid value range. The request reference
establishes the relationship between request and response.
● Request ID:
02 hex ––> This identifier is required for a write request.
● Axis:
02 hex ––> The parameters are written to drive 2.
● No. of parameters
04 hex ––> The multi-parameter request comprises 4 individual parameter requests.
1. parameter address ... 4th parameter address
● Attribute:
10 hex ––> The parameter values are to be written.
● No. of elements
01 hex ––> 1 array element is written.
● Parameter number
Specifies the number of the parameter to be written (p1055, p1056, p1058, p1059).
