78 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Chapter 5 Power Quality Monitoring
Individual harmonic results are returned in an array of data tables. You can view
any harmonic results table by selecting it from the PowerQuality >
Harmonics_Results tab in the PowerMonitor 5000 web page. The available
harmonic results data tables are listed below.
• PowerQuality.Total_kW_H1_RMS (DC…31)
• PowerQuality.Total_kW_H2_RMS (32…63)
• PowerQuality.Total_kVAR_H1_RMS (DC…31)
• PowerQuality.Total_kVAR_H2_RMS (32…63)
• PowerQuality.Total_kVA_H1_RMS (DC…31)
• PowerQuality.Total_kVA_H2_RMS (32…63)
• PowerQuality.V1_N_Volts_H1_RMS (DC…31)
• PowerQuality.V1_N_Volts_H2_RMS (32…63)
• PowerQuality.V2_N_Volts_H1_RMS (DC…31)
• PowerQuality.V2_N_Volts_H2_RMS (32…63)
• PowerQuality.V3_N_Volts_H1_RMS (DC…31)
• PowerQuality.V3_N_Volts_H2_RMS (32…63)
• PowerQuality.VN_G_Volts_H1_RMS (DC…31)
• PowerQuality.VN_G_Volts_H2_RMS (32…63)
• PowerQuality.V1_V2_Volts_H1_RMS (DC…31)
• PowerQuality.V1_V2_Volts_H2_RMS (32…63)
• PowerQuality.V2_V3_Volts_H1_RMS (DC…31)
• PowerQuality.V2_V3_Volts_H2_RMS (32…63)
• PowerQuality.V3_V1_Volts_H1_RMS (DC…31)
• PowerQuality.V3_V1_Volts_H2_RMS (32…63)
• PowerQuality.I1_Amps_H1_RMS (DC…31)
• PowerQuality.I1_Amps_H2_RMS (32…63)
• PowerQuality.I2_Amps_H1_RMS (DC…31)
• PowerQuality.I2_Amps_H2_RMS (32…63)
• PowerQuality.I3_Amps_H1_RMS (DC…31)
• PowerQuality.I3_Amps_H2_RMS (32…63)
• PowerQuality.I4_Amps_H1_RMS (DC…31)
• PowerQuality.I4_Amps_H2_RMS (32…63)
• PowerQuality.L1_kW_H1_RMS (DC…31)
• PowerQuality.L1_kW_H2_RMS (32…63)
• PowerQuality.L2_kW_H1_RMS (DC…31)
• PowerQuality.L2_kW_H2_RMS (32…63)
• PowerQuality.L3_kW_H1_RMS (DC…31)
• PowerQuality.L3_kW_H2_RMS (32…63)
• PowerQuality.L1_kVAR_H1_RMS (DC…31)
• PowerQuality.L1_kVAR_H2_RMS (32…63)
• PowerQuality.L2_kVAR_H1_RMS (DC…31)
• PowerQuality.L2_kVAR_H2_RMS (32…63)
