PowerMonitor 5000 Unit Data Tables Appendix A
Configuration.Setpoint_Outputs
Table 71 - Table Properties
CIP Instance Number 812
PCCC File Number N21
No. of Elements 100
Length in Words 100
Data Type Int16
Data Access Read/Write
Table 72 - Configuration.Setpoint_Outputs Data Table
Element
Number Type Tag Name Description Default Range
0 Int16 Setpoint Output
1 Input Source Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10 1 0…10 (M5)
0…30 (M6)
1 Int16 Setpoint Output
1 Action Selects the output action to perform when setpoint is asserted. See the Setpoint Output Action List . 0 0…19 (M5)
0…30 (M6)
2 Int16 Setpoint Output
2 Input Source Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10 2 0…10 (M5)
0…30 (M6)
3 Int16 Setpoint Output
2 Action Selects the output action to perform when setpoint is asserted. See the Setpoint Output Action List . 0 0…19 (M5)
0…30 (M6)
4 Int16 Setpoint Output
3 Input Source Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10 3 0…10 (M5)
0…30 (M6)
5 Int16 Setpoint Output
3 Action Selects the output action to perform when setpoint is asserted. See the Setpoint Output Action List . 0 0…19 (M5)
0…30 (M6)
6 Int16 Setpoint Output
4 Input Source Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10 4 0…10 (M5)
0…30 (M6)
7 Int16 Setpoint Output
4 Action Selects the output action to perform when setpoint is asserted. See the Setpoint Output Action List . 0 0…19 (M5)
0…30 (M6)
