Appendix A
PowerMonitor 5000 Unit Data Tables
29
Int16
Setpoint Output
15 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
30
Int16
Setpoint Output
16 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
1
0…30 (M6)
31
Int16
Setpoint Output
16 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
32
Int16
Setpoint Output
17 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
1
0…30 (M6)
33
Int16
Setpoint Output
17 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
34
Int16
Setpoint Output
18 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
1
0…30 (M6)
35
Int16
Setpoint Output
18 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
36
Int16
Setpoint Output
19 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
1
0…30 (M6)
37
Int16
Setpoint Output
19 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
38
Int16
Setpoint Output
20 Input Source
Selects the source for output. Setpoint or gate output state.
0 = No source
1 = Setpoint 1
2 = Setpoint 2…
20 = Setpoint 20
21 = Level1_G1 ...
30 = Level1_G10
1
0…30 (M6)
39
Int16
Setpoint Output
20 Action
Selects the output action to perform when setpoint is asserted. See the
. 0
0…30 (M6)
40…99
Int16
Reserved
Future Use
0
0
Table 72 - Configuration.Setpoint_Outputs Data Table
Element
Number
Type
Tag Name
Description
Default
Range
