Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 325
PowerMonitor 5000 Unit Data Tables Appendix A
4 Real Status 1 Count x M
Register Set Value Status 1 Count Register Start Value x 1,000,000 0 0…9,999,999
5 Real Status 1 Count X 1
Register Set Value Status 1 Count Register Start Value x 1 0 0…999,999
6 Real Status 2 Count x M
Register Set Value Status 2 Count Register Start Value x 1,000,000 0 0…9,999,999
7 Real Status 2 Count X 1
Register Set Value Status 2 Count Register Start Value x 1 0 0…999,999
8 Real Status 3 Count x M
Register Set Value Status 3 Count Register Start Value x 1,000,000 0 0…9,999,999
9 Real Status 3 Count X 1
Register Set Value Status 3 Count Register Start Value x 1 0 0…999,999
10 Real Status 4 Count x M
Register Set Value Status 4 Count Register Start Value x 1,000,000 0 0…9,999,999
11 Real Status 4 Count X 1
Register Set Value Status 4 Count Register Start Value x 1 0 0…999,999
12 Real GWh Fwd Register Set
Value Sets the GWh Fwd Register to the desired Value 0 0…9,999,999
13 Real kWh Fwd Register Set
Value Sets the kWh Fwd Register to the desired Value 0 0…999,999
14 Real GWh Rev Register Set
Value Sets the GWh Rev Register to the desired Value 0 0…9,999,999
15 Real kWh Rev Register Set
Value Sets the kWh Rev Register to the desired Value 0 0…999,999
16 Real GVARh Fwd Register Set
Value Sets the GVARh Fwd Register to the desired Value 0 0…9,999,999
17 Real kVARh Fwd Register Set
Value Sets the kVARh Fwd Register to the desired Value 0 0…999,999
18 Real GVARh Rev Register Set
Value Sets the GVARh Rev Register to the desired Value 0 0…9,999,999
19 Real kVARh Rev Register Set
Value Sets the kVARh Rev Register to the desired Value 0 0…999,999
20 Real GVAh Register Set Value Sets the GVAh Register to the desired Value 0 0…9,999,999
21 Real kVAh Register Set Value Sets the kVAh Register to the desired Value 0 0…999,999
22 Real GAh Register Set Value Sets the GAh Register to the desired Value 0 0…9,999,999
23 Real kAh Register Set Value Sets the kAh Register to the desired Value 0 0…999,999
24 Real Clear Waveform File ID Waveform file identity
0 = Clear All
If the identiry is not known, the command is ignored. 0 0…3276
25…44 Real Reserved For future use 0 0
Table 130 - Command.System_Registers Data Table
Element
Number Type Tag Name Description Default Range
