Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 313
PowerMonitor 5000 Unit Data Tables Appendix A
Status.IEEE1588 (M6 model)
Table 121 - Table Properties
CIP Instance Number 873
PCCC File Number N82
No. of Elements 49
Length in Words 49
Data Type INT16
Data Access Read Only
Table 122 - Status.IEEE1588 Data Table (M6 model)
Element
Number Type Tag Name Description Range
0 Int16 IEEE1588_Version IEEE1588 Version 2 2
1 Int16 PTPEnable PTPEnable specifies the enable status for the Precision Time Protocol on the device. 0,1
2 Int16 IsSynchronized IsSynchronized specifies whether the local clock is synchronized with a master reference clock. The
value is 1 if the local clock is synchronized and 0 if the local clock is not synchronized. A clock is
synchronized if it has one port in the slave state and is receiving updates from the time master. 0,1
3 Int16 SystemTimeMicroseconds_A SystemTimeMicroseconds specifies a 64-bit value of the current system time in units of
microseconds. (Bit 0 to bit 15) 0…0xffff
4 Int16 SystemTimeMicroseconds_B SystemTimeMicroseconds specifies a 64-bit value of the current system time in units of
microseconds. (Bit 16 to bit 31) 0…0xffff
5 Int16 SystemTimeMicroseconds_C SystemTimeMicroseconds specifies a 64-bit value of the current system time in units of
microseconds. (Bit 32 to bit 47) 0…0xffff
6 Int16 SystemTimeMicroseconds_D SystemTimeMicroseconds specifies a 64-bit value of the current system time in units of
microseconds. (Bit 48 to bit 63) 0…0xffff
7 Int16 SystemTimeNanoseconds_A SystemTimeNanoseconds specifies a 64-bit value of the current system time in units of
nanoseconds. (Bit 0 to bit 15) 0…0xffff
8 Int16 SystemTimeNanoseconds_B SystemTimeNanoseconds specifies a 64-bit value of the current system time in units of
nanoseconds. (Bit 16 to bit 31) 0…0xffff
9 Int16 SystemTimeNanoseconds_C SystemTimeNanoseconds specifies a 64-bit value of the current system time in units of
nanoseconds. (Bit 32 to bit 47) 0…0xffff
10 Int16 SystemTimeNanoseconds_D SystemTimeNanoseconds specifies a 64-bit value of the current system time in units of
nanoseconds. (Bit 48 to bit 63) 0…0xffff
11 Int16 OffsetFromMaster_A OffsetFromMaster specifies the amount of deviation between the local clock and its master clock in
nanoseconds.(Bit 0 to bit 15) 0…0xffff
12 Int16 OffsetFromMaster_B OffsetFromMaster specifies the amount of deviation between the local clock and its master clock in
nanoseconds. (Bit 16 to bit 31) 0…0xffff
13 Int16 OffsetFromMaster_C OffsetFromMaster specifies the amount of deviation between the local clock and its master clock in
nanoseconds. (Bit 32 to bit 47) 0…0xffff
14 Int16 OffsetFromMaster_D OffsetFromMaster specifies the amount of deviation between the local clock and its master clock in
nanoseconds. (Bit 48 to bit 63) 0…0xffff
15 Int16 MaxOffsetFromMaster_A MaxOffsetFromMaster specifies the absolute value of the maximum amount of deviation between
the local clock and the master clock in nanoseconds since last set. (Bit 0 to bit 15) 0…0xffff
16 Int16 MaxOffsetFromMaster_B MaxOffsetFromMaster specifies the absolute value of the maximum amount of deviation between
the local clock and the master clock in nanoseconds since last set. (Bit 16 to bit 31) 0…0xffff
17 Int16 MaxOffsetFromMaster_C MaxOffsetFromMaster specifies the absolute value of the maximum amount of deviation between
the local clock and the master clock in nanoseconds since last set. (Bit 32 to bit 47) 0…0xffff
18 Int16 MaxOffsetFromMaster_D MaxOffsetFromMaster specifies the absolute value of the maximum amount of deviation between
the local clock and the master clock in nanoseconds since last set. (Bit 48 to bit 63) 0…0xffff
