Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 357
PowerMonitor 5000 Unit Data Tables Appendix A
PowerQuality.IEEE1159_Results (M6 model)
Table 181 - Table Properties
CIP Instance Number 863
PCCC File Number F72
No. of Elements 26
Length in Words 52
Data Type Real
Data Access Read Only
Table 182 - PowerQuality.IEEE1159_Results Data Table
Element
Number Type Tag Name Description Units Range
0 Real Metering_Date_Stamp Date of cycle collection MMDDYY MMDDYY 0…123199
1 Real Metering_Time_Stamp Time of cycle collection hhmmss hhmmss 0…235959
2 Real Metering Microsecond Stamp Microsecond of cycle collection uS 0.000…999999
3 Real IEEE1159_Volts_Imbalance_% The rolling average for IEEE1159 voltage imbalance % 0.0…100.00
4 Real IEEE1159_Current_Imbalance_% The rolling average for IEEE1159 current imbalance % 0.0…100.00
5 Real IEEE1159_Power_Frequency_Hz The rolling variation from nominal frequency setting. Hz 0.0…70.00
6 Real IEEE1159_V1_DC_Offset_% The rolling average for V1 voltage dc offset % 0.0…100.00
7 Real IEEE1159_V2_DC_Offset_% The rolling average for V2 voltage dc offset % 0.0…100.00
8 Real IEEE1159_V3_DC_Offset_% The rolling average for V3 voltage dc offset % 0.0…100.00
9 Real IEEE1159_V1_THD_% The rolling average for V1 Voltage THD % 0.0…100.00
10 Real IEEE1159_V2_THD_% The rolling average for V2 Voltage THD % 0.0…100.00
11 Real IEEE1159_V3_THD_% The rolling average for V3 Voltage THD % 0.0…100.00
12 Real IEEE1159_I1_THD_% The rolling average for I1 Current THD % 0.0…100.00
13 Real IEEE1159_I2_THD_% The rolling average for I2 Current THD % 0.0…100.00
14 Real IEEE1159_I3_THD_% The rolling average for I3 Current THD % 0.0…100.00
15…25 Real Reserved Reserved 0.0
