Appendix A PowerMonitor 5000 Unit Data Tables
Status.Alarms
Table 115 - Table Properties
CIP Instance Number 832
PCCC File Number N41
No. of Elements 32
Length in Words 32
Data Type Int16
Data Access Read Only
Table 116 - Status.Alarms Data Table
Element
Number Type Tag Name Description Range
0 Int16 Setpoints_1_10_Active Actuation Status of Setpoints 1…10 0…65,535
Bit 0 Setpoint1_Active 1 Indicates the setpoint 1 is Active 0 or 1
Bit 1 Setpoint2_Active 1 Indicates the setpoint 2 is Active 0 or 1
Bit 2 Setpoint3_Active 1 Indicates the setpoint 3 is Active 0 or 1
Bit 3 Setpoint4_Active 1 Indicates the setpoint 4 is Active 0 or 1
Bit 4 Setpoint5_Active 1 Indicates the setpoint 5 is Active 0 or 1
Bit 5 Setpoint6_Active 1 Indicates the setpoint 6 is Active 0 or 1
Bit 6 Setpoint7_Active 1 Indicates the setpoint 7 is Active 0 or 1
Bit 7 Setpoint8_Active 1 Indicates the setpoint 8 is Active 0 or 1
Bit 8 Setpoint9_Active 1 Indicates the setpoint 9 is Active 0 or 1
Bit 9 Setpoint10_Active 1 Indicates the setpoint 10 is Active 0 or 1
Bit 10…15 Reserved Reserved for future use 0
1 Int16 Setpoints_11_20_Active (M6) Actuation Status of Setpoints 11 … 20 0 … 65535
Bit 0 Setpoint11_Active 1 Indicates the setpoint 11 is Active 0 or 1
Bit 1 Setpoint12_Active 1 Indicates the setpoint 12 is Active 0 or 1
Bit 2 Setpoint13_Active 1 Indicates the setpoint 13 is Active 0 or 1
Bit 3 Setpoint14_Active 1 Indicates the setpoint 14 is Active 0 or 1
Bit 4 Setpoint15_Active 1 Indicates the setpoint 15 is Active 0 or 1
Bit 5 Setpoint16_Active 1 Indicates the setpoint 16 is Active 0 or 1
Bit 6 Setpoint17_Active 1 Indicates the setpoint 17 is Active 0 or 1
Bit 7 Setpoint18_Active 1 Indicates the setpoint 18 is Active 0 or 1
Bit 8 Setpoint19_Active 1 Indicates the setpoint 19 is Active 0 or 1
Bit 9 Setpoint20_Active 1 Indicates the setpoint 20 is Active 0 or 1
Bit 10 … 15 Reserved Future Use 0
