Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 363
PowerMonitor 5000 Unit Data Tables Appendix A
Table 189 - PowerQuality.Harmonic Results Data Table template, H1 order range (DC …31)
Element
Number Type Tag Name Description Units Range
0 Real Metering_Date_Stamp Date of cycle collection MMDDYY MMDDYY 0…123199
1 Real Metering_Time_Stamp Time of cycle collection hhmmss hhmmss 0…235959
2 Real Metering_Microsecond_Stamp Microsecond of cycle collection uS 0.000…999999
3 Real __DC__
The value of the specified harmonic component: RMS
magnitude or Angle Same as string in
Tag Name: kW kVAR kVA
Volts Amps 0…9.999E15
4 Real __h1__
0…9.999E15
5 Real __h2__
0…9.999E15
6 Real __h3__
0…9.999E15
7 Real __h4__
0…9.999E15
8 Real __h5__
0…9.999E15
9 Real __h6__
0…9.999E15
10 Real __h7__
0…9.999E15
11 Real __h8__
0…9.999E15
12 Real __h9__
0…9.999E15
13 Real __h10_
_ 0…9.999E15
14 Real __h11_
_ 0…9.999E15
15 Real __h12_
_ 0…9.999E15
16 Real __h13_
_ 0…9.999E15
17 Real __h14_
_ 0…9.999E15
18 Real __h15_
_ 0…9.999E15
19 Real __h16_
_ 0…9.999E15
20 Real __h17_
_ 0…9.999E15
21 Real __h18_
_ 0…9.999E15
22 Real __h19_
_ 0…9.999E15
23 Real __h20_
_ 0…9.999E15
