Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 329
PowerMonitor 5000 Unit Data Tables Appendix A
MeteringResults.RealTime_VIF_Power
Table 135 - Table Properties
CIP Instance Number 844
PCCC File Number F53
No. of Elements 56
Length in Words 112
Data Type Real
Data Access Read Only
Table 136 - MeteringResults.RealTime_VIF_Power Data Table
Element
Number Type Tag Name Description Units Range
0 Real Metering Date Stamp Date of cycle collection MM:DD:YY MM:DD:YY 0…123199
1 Real Metering Time Stamp Time of cycle collection HH:MM:SS HH:MM:SS 0…235959
2 Real Metering Microsecond Stamp Microsecond of cycle collection uS 0.000…999999
3 Real V1_N_Volts V1 to N true RMS voltage V 0…9.999E15
4 Real V2_N_Volts V2 to N true RMS voltage V 0…9.999E15
5 Real V3_N_Volts V3 to N true RMS voltage V 0…9.999E15
6 Real VN_G_Volts VN to G true RMS voltage V 0…9.999E15
7 Real Avg_V_N_Volts Average of V1, V2 and V3 V 0…9.999E15
8 Real V1_V2_Volts V1 to V2 true RMS voltage V 0…9.999E15
9 Real V2_V3_Volts V2 to V3 true RMS voltage V 0…9.999E15
10 Real V3_V1_Volts V3 to V1 true RMS voltage V 0…9.999E15
11 Real Avg_VL_VL_Volts Average of V1_V2, V2_V3 and V3_V1 V 0…9.999E15
12 Real I1_Amps I1 true RMS amps A 0…9.999E15
13 Real I2_Amps I2 true RMS amps A 0…9.999E15
14 Real I3_Amps I3 true RMS amps A 0…9.999E15
15 Real I4_Amps I4 true RMS amps A 0…9.999E15
16 Real Avg_Amps Average I1, I2 and I3 amps A 0…9.999E15
17 Real Frequency_Hz Last Line Frequency Calculated Hz 40.00…70.00
18 Real Avg_Frequency_Hz Average Frequency over 6 cycles Hz 40.00…70.00
19 Real L1_kW L1 real power kW -9.999E15…9.999E15
20 Real L2_kW L2 real power kW -9.999E15…9.999E15
21 Real L3_kW L3 real power kW -9.999E15…9.999E15
22 Real Total_kW Total real power kW -9.999E15…9.999E15
23 Real L1_kVAR L1 reactive power kVAR -9.999E15…9.999E15
24 Real L2_kVAR L2 reactive power kVAR -9.999E15…9.999E15
25 Real L3_kVAR L3 reactive power kVAR -9.999E15…9.999E15
26 Real Total_kVAR Total reactive power kVAR -9.999E15…9.999E15
27 Real L1_kVA L1 apparent power kVA 0…9.999E15
28 Real L2_kVA L2 apparent power kVA 0…9.999E15
