Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 157
Logic Functions Chapter 7
Commands
The following command parameters are found in the
Command.System_Registers table.
Command Word 1
Set this command word value to set or reset (to zero) a scaled status input counter
value. These are the selections:
6 = Set Status 1 Count
7 = Set Status 2 Count
8 = Set Status 3 Count
9 = Set Status 4 Count
These commands operate by using the values contained in the tags listed below.
The default values are zero. The semantics are the same as described in the Status
sub-clause above.
Status 1 Count x M Register Set Value
Status 1 Count X 1 Register Set Value
Status 2 Count x M Register Set Value
Status 2 Count X 1 Register Set Value
Status 3 Count x M Register Set Value
Status 3 Count X 1 Register Set Value
Status 4 Count x M Register Set Value
Status 4 Count X 1 Register Set Value
Related Functions
Configuration lock.
Setpoints A Setpoint tracks the value of a user-selected parameter and when the value meets
user-defined criteria, sets the corresponding Setpoint_Active flag and executes an
optional user-selected action.
Applications
• M5 model: 10 simple setpoints
• M6 model: 20 simple or logical setpoints with 10 logic gates
