Appendix A
PowerMonitor 5000 Unit Data Tables
5
Real
X_(0 + Order * 32)
The returned value X_(h) (RMS magnitude or angle) for the spectral component specified by
Channel at harmonic h
V, A, or
degrees,
depending
on value of
Channel
0…9.999E15
6
Real
X_(1 + Order * 32)
0…9.999E15
7
Real
X_(2 + Order * 32)
0…9.999E15
8
Real
X_(3 + Order * 32)
0…9.999E15
9
Real
X_(4 + Order * 32)
0…9.999E15
10
Real
X_(5 + Order * 32)
0…9.999E15
11
Real
X_(6 + Order * 32)
0…9.999E15
12
Real
X_(7 + Order * 32)
0…9.999E15
13
Real
X_(8 + Order * 32)
0…9.999E15
14
Real
X_(9 + Order * 32)
0…9.999E15
15
Real
X_(10 + Order * 32)
0…9.999E15
16
Real
X_(11 + Order * 32)
0…9.999E15
17
Real
X_(12 + Order * 32)
0…9.999E15
18
Real
X_(13 + Order * 32)
0…9.999E15
19
Real
X_(14 + Order * 32)
0…9.999E15
20
Real
X_(15 + Order * 32)
0…9.999E15
21
Real
X_(16 + Order * 32)
0…9.999E15
22
Real
X_(17 + Order * 32)
0…9.999E15
23
Real
X_(18 + Order * 32)
0…9.999E15
24
Real
X_(19 + Order * 32)
0…9.999E15
25
Real
X_(20 + Order * 32)
0…9.999E15
26
Real
X_(21 + Order * 32)
0…9.999E15
27
Real
X_(22 + Order * 32)
0…9.999E15
28
Real
X_(23 + Order * 32)
0…9.999E15
29
Real
X_(24 + Order * 32)
0…9.999E15
30
Real
X_(25 + Order * 32)
0…9.999E15
31
Real
X_(26 + Order * 32)
0…9.999E15
32
Real
X_(27 + Order * 32)
0…9.999E15
33
Real
X_(28 + Order * 32)
0…9.999E15
34
Real
X_(29 + Order * 32)
0…9.999E15
35
Real
X_(30 + Order * 32)
0…9.999E15
36
Real
X_(31 + Order * 32)
0…9.999E15
Table 180 - PowerQuality.Harmonics_Results Data Table
Element
Number
Type
Tag Name
Description
Units
Range
