Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 263
PowerMonitor 5000 Unit Data Tables Appendix A
Configuration.Setpoints_16_20 (M6 model)
Table 67 - Table Properties
CIP Instance Number 810
PCCC File Number F19
No. of Elements 50
Length in Words 100
Data Type Real
Data Access Read/Write
Table 68 - Configuration.Setpoints_16_20 Data Table
Element
Number Type Tag Name Description Default Range
0 Real Parameter
Selection 16 Selection of the input parameter from the Simple Setpoint Parameter List. 0 0…105
1 Real Input Reference
Selection 16 Selects the type of input conditioning for non boolean parameters.
0 = Absolute Value 0 0
2 Real Test Condition 16 0 = Disabled
1 = Less Than
2 = Greater Than
3 = Equals 0 0…3
3 Real Evaluation Type
16 0 = Magnitude
1 = State
2 = Percent of Reference (not supported in the M5 model)
3 = Percent of Sliding Reference (not supported in the M5 model) 0 0…3
4 Real Threshold 16 The value, percent or state that triggers the output action. 0 -10,000,000…
10,000,000
5 Real Hysteresis 16 The value in magnitude or percent of reference at which the output action is deasserted.
Example: A less than condition deasserts at (threshold + hysteresis), a greater than condition
deasserts at (threshold - hysteresis). 0 0…10,000,000
6 Real Assert Delay
Seconds 16 The amount of time to delay the output action after a setpoint trigger occurs. Minimum equals
realtime update rate setting. 0 0.000…3600
7 Real Deassert Delay
Seconds 16 The amount of time to delay deassertion after the setpoint trigger releases. Minimum equals
realtime update rate setting. 0 0.000…3600
8 Real Parameter
Selection 17 Selection of the input parameter from the Setpoint Parameter Selection List . 0 0…105
9 Real Input Reference
Selection 17 Selects the type of input conditioning for non boolean parameters.
0 = Absolute Value 0 0
10 Real Test Condition 17 0 = Disabled
1 = Less Than
2 = Greater Than
3 = Equals 0 0…3
11 Real Evaluation Type
17 0 = Magnitude
1 = State
2 = Percent of Reference (not supported in the M5 model)
3 = Percent of Sliding Reference (not supported in the M5 model) 0 0…3
12 Real Threshold 17 The value, percent, or state that triggers the output action. 0 -10,000,000…
10,000,000
