Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 187
Communication Chapter 9
EtherNet/IP Object Model This section provides the object model for a PowerMonitor 5000 device type on
an EtherNet/IP network. The table below indicates the following:
• The object classes present in this device
• Whether or not the class is required
• The number of instances present in each class
Object Class List
The PowerMonitor 5000 unit supports the following CIP classes.
Table 32 - CIP Object Class List
Object Class Need in Implementation Number of Instances
Identity (1, 1hex) Required 1
Message Router (2, 2hex) Required 1
TCP/IP Interface Object (245, F5hex) Required 1
Ethernet Link Object (246, F6hex) Required 1 Required (2 Optional)
Connection Manager Object (6, 6hex) Required 1
Assembly Object (4, 4 hex) Required Minimum of 3
Parameter Object (15, Fhex) Required Product Specific
Parameter Group Object (16, 10hex) Optional Product Specific
Non-Volatile Storage Object (161, A1hex) Required Product Specific
File Object (55, 37hex) Required Minimum of 1
Time-Sync Object (67, 43hex) Optional 1
QoS Object (72, 48hex) Optional 1
PCCC Object (103, 67hex) Optional 1
Symbol Object (107, 6Bhex) Optional Product Specific
User Defined Template Object (108, 6Chex) Optional Product Specific
File Manager Object (794, 31Ahex) Optional 1
Email Object (815, 32Fhex) Optional 1
Device Level Ring Object (71, 47hex) Optional 1
Energy Object (78, 4Ehex) Required 1
Electrical Energy Object (79, 4Fhex) Required 1
