Rockwell Automation 1426 PowerMonitor 5000 Unit User Manual
Page 273
Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
273
PowerMonitor 5000 Unit Data Tables
Appendix A
41
Int16
L1_G9 Input 1
Selects the first input parameter for the gate. Each gate has four inputs.
0 = Disabled
1 = Setpoint 1
2 = Setpoint 2
3 = Setpoint 3
…
20 = Setpoint 20
IMPORTANT: Negative numbers invert the input.
0
-20…20
42
Int16
L1_G9 Input 2
Selects the second input parameter for the gate. Each gate has four inputs.
0 = Disabled
1 = Setpoint 1
2 = Setpoint 2
3 = Setpoint 3
…
20 = Setpoint 20
IMPORTANT: Negative numbers invert the input.
0
-20…20
43
Int16
L1_G9 Input 3
Selects the third input parameter for the gate. Each gate has four inputs.
0 = Disabled
1 = Setpoint 1
2 = Setpoint 2
3 = Setpoint 3
…
20 = Setpoint 20
IMPORTANT: Negative numbers invert the input.
0
-20…20
44
Int16
L1_G9 Input 4
Selects the fourth input parameter for the gate. Each gate has four inputs.
0 = Disabled
1 = Setpoint 1
2 = Setpoint 2
3 = Setpoint 3
…
20 = Setpoint 20
IMPORTANT: Negative numbers invert the input.
0
-20…20
45
Int16
Logic Level 1
Gate 10 Function
Selects the logic type
0 = disabled
1 = AND
2 = NAND
3 = OR
4 = NOR
5 = XOR
6 = XNOR
IMPORTANT: XOR and XNOR use Inputs 1 and 2 only.
0
0…6
46
Int16
L1_G10 Input 1
Selects the first input parameter for the gate. Each gate has four inputs.
0 = Disabled
1 = Setpoint 1
2 = Setpoint 2
3 = Setpoint 3
…
20 = Setpoint 20 IMPORTANT: Negative numbers invert the input.
0
-20…20
Table 70 - Configuration.Setpoint_Logic Data Table
Element
Number
Type
Tag Name
Description
Default
Range
