Appendix A PowerMonitor 5000 Unit Data Tables
Status.TableWrite
27 Real Current_Phase_2_Magnitude Shows the present magnitude of this phase. 0…9,999,999
28 Real Current_Phase_3_Angle Shows the present phase angle of this channel. 0…359.99
29 Real Current_Phase_3_Magnitude Shows the present magnitude of this phase. 0…9,999,999
30…32 Real Reserved Reserved for future use. 0
Table 110 - Status.Wiring_Diagnostics Data Table
Element
Number Type Tag Name Description Range
Table 111 - Table Properties
CIP Instance Number 830
PCCC File Number N39
No. of Elements 11
Length in Words 11
Data Type Int16
Data Access Read Only
Table 112 - Status.TableWrite Data Table
Element
Number Type Tag Name Description Range
0 Int16 Table_Number_or_Instance Indicates the last table that was written. 0…256
1 Int16 Offending_Element If the most recent write was successful this returns a ( -1).
If the write was unsuccessful this is the first rejected
element in the table write. 0…256
2 Int16 Configuration_Lock_On If a write was made to a table that has elements that are
locked this value is 1. 0 or 1
3 Int16 Password_is_not_validated A write to a table could not be performed because the
password is not validated or active. 0 or 1
4 Int16 Password_Activated The password is active by user. 0 or 1
5 Int16 Admin_Name_Or_Password_Rejected Admin type account rejected. 0 or 1
6 Int16 Admin_Password_Active Admin type account active. 0 or 1
7 Int16 Application_Name_Or_Password_Rejected Application type account rejected. 0 or 1
8 Int16 Application_Password_Active Application type account active. 0 or 1
9 Int16 UserType_Name_Or_Password_Rejected User type account rejected. 0 or 1
10 Int16 User_Password_Active User type account active. 0 or 1
11 Int16 Security Status 0 = disabled
1 = enabled 0 or 1
12 Int16 Exclusive Ownership Conflict 0 = no conflict
1 = conflict, configuration owned by Logix controller 0 or 1
