248 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
Configuration.System.General
Table 55 - Table Properties
CIP Instance Number 803
PCCC File Number F12
No. of Elements 50
Length in Words 100
Data Type Real
Data Access Read/Write
Table 56 - Configuration.System.General Data Table
Element
Number Type Tag Name Description Default Range
0 Real Log_Status_Input_Changes 0=Disable recording of status input changes into the event log
1=Enable recording of event input changes into the event log 0 0…1
1 Real Use_Daylight_Savings_Correction 0 = Disable Daylight Savings
1 = Enable Daylight Savings 0 0…1
2 Real Daylight_Savings_Month/Week/
Day_Start This is the day that the power monitor adds an hour to the time. This feature also
looks at Ethernet SNTP offset and corrects for Daylight Savings.
Example: 040107 = April/1st week/Saturday
Month Settings:
01 = January…
12 = December
Week Settings:
01 = 1st week…
05 = Last Week
Day of the Week Settings:
01 = Sunday…
07 = Saturday 030201 March,
2nd, Sunday 010101
…
120507
3 Real Hour_of_Day_Start The hour of day the daylight savings adjustment is made to add an hour. 2 0…23
4 Real Return_from_Daylight_Savings_
Month/Week/Day This is the day that the power monitor subtracts an hour from the time. This feature
also looks at Ethernet SNTP offset and corrects for the return from Daylight Savings.
Month Settings:
01 = January…
12 = December
Week Settings:
01 = 1st week…
05 = Last Week
Day of the Week Settings:
01 = Sunday…
07 = Saturday 110101
November, 1st,
Sunday 010101
…
120507
5 Real Hour_of_Day_End The hour of day the daylight savings adjustment is made to subtract an hour. 2 0…23
6 Real KYZ_Solid_State_Output_
Parameter The parameter selected pulses the KYZ output at a rate that equals the parameter
value divided by KYZ scale.
0 = Disable
1 = Wh Fwd
2 = Wh Rev
3 = VARh Fwd
4 = VARh Rev
5 = VAh
6 = Ah 0 0…6
