Rockwell Automation 1426 PowerMonitor 5000 Unit User Manual
Page 239
Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
239
PowerMonitor 5000 Unit Data Tables
Appendix A
29
Demand_Broadcast_Mode_Select
Int16
N/A
0…1
0
30
Demand_Broadcast_Port
Int16
N/A
300…400
300
31
KYZ_Solid_State_Output_Parameter
Real
N/A
0…9
0
32
KYZ_Solid_State_Output_Scale
Real
N/A
1…100,000
1000
33
KYZ_Pulse_Duration_Setting
Real
N/A
0 or 50 …1000
250
34
Output_Relay_1_Output_Parameter
Real
N/A
0…9
0
35
Output_Relay_1_Output_Scale
Real
N/A
1…100,000
1000
36
Output_Relay_1_Pulse_Duration_Setting
Real
N/A
0 or 50 …1000
250
37
Output_Relay_2_Output_Parameter
Real
N/A
0…9
0
38
Output_Relay_2_Output_Scale
Real
N/A
1…100,000
1000
39
Output_Relay_2_Pulse_Duration_Setting
Real
N/A
0 or 50 …1000
250
40
Output_Relay_3_Output_Parameter
Real
N/A
0…9
0
41
Output_Relay_3_Output_Scale
Real
N/A
1…100,000
1000
42
Output_Relay_3_Pulse_Duration_Setting
Real
N/A
0 or 50…1000
250
43
Status_Input_1_Input_Scale
Real
N/A
1…1,000,000
1
44
Status_Input_2_Input_Scale
Real
N/A
1…1,000,000
1
45
Status_Input_3_Input_Scale
Real
N/A
1…1,000,000
1
46
Status_Input_4_Input_Scale
Real
N/A
1…1,000,000
1
47
Default_KYZ_State_On_Comm_Loss
Real
N/A
0…3
0
48
Default_Relay_1_State_On_Comm_Loss
Real
N/A
0…3
0
49
Default_Relay_2_State_On_Comm_Loss
Real
N/A
0…3
0
50
Default_Relay_3_State_On_Comm_Loss
Real
N/A
0…3
0
51
Clear Energy Counters
Int16
N/A
0…1
0
52
Clear Energy log
Int16
N/A
0…1
0
Table 46 - Configuration Parameter Object Table
Instance Number
Parameter Object Name
Type
Units
Range
Default Value
