Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 321
PowerMonitor 5000 Unit Data Tables Appendix A
Statistics.Setpoint_Logic (M6 model)
Table 127 - Table Properties
CIP Instance Number 828
PCCC File Number N37
No. of Elements 112
Length in Words 112
Data Type Int16
Data Access Read Only
Table 128 - Statistics.Setpoint_Logic Data Table
Element
Number Type Tag Name Description Units Range
0 Int16 Level1 Gate1 Seconds
Accumulator Time accumulator counter for seconds part of total accumulated time. Sec 0…999
1 Int16 Level1 Gate1 Minutes
Accumulator Time accumulator counter for minutes part of total accumulated time. Min 0…59
2 Int16 Level1 Gate1 Hours
Accumulator Time accumulator counter for total hours of accumulated time. Hr 0…9999
3 Int16 Level1 Gate1 Transitions to
Active x1 The number of actuations for setpoint times 1 x1 0…999
4 Int16 Level1 Gate1 Transitions to
Active x1000 The number of actuations for setpoint times 1000. x1000 0…9999
5 Int16 Level1 Gate2 Seconds
Accumulator Time accumulator counter for seconds part of total accumulated time. Sec 0…999
6 Int16 Level1 Gate2 Minutes
Accumulator Time accumulator counter for minutes part of total accumulated time. Min 0…59
7 Int16 Level1 Gate2 Hours
Accumulator Time accumulator counter for total hours of accumulated time. Hr 0…9999
8 Int16 Level1 Gate2 Transitions to
Active x1 The number of actuations for setpoint times 1 x1 0…999
9 Int16 Level1 Gate2 Transitions to
Active x1000 The number of actuations for setpoint times 1000. x1000 0…9999
10 Int16 Level1 Gate3 Seconds
Accumulator Time accumulator counter for seconds part of total accumulated time. Sec 0…999
11 Int16 Level1 Gate3 Minutes
Accumulator Time accumulator counter for minutes part of total accumulated time. Min 0…59
12 Int16 Level1 Gate3 Hours
Accumulator Time accumulator counter for total hours of accumulated time. Hr 0…9999
13 Int16 Level1 Gate3 Transitions to
Active x1 The number of actuations for setpoint times 1 x1 0…999
14 Int16 Level1 Gate3 Transitions to
Active x1000 The number of actuations for setpoint times 1000. x1000 0…9999
15 Int16 Level1 Gate4 Seconds
Accumulator Time accumulator counter for seconds part of total accumulated time. Sec 0…999
16 Int16 Level1 Gate4 Minutes
Accumulator Time accumulator counter for minutes part of total accumulated time. Min 0…59
17 Int16 Level1 Gate4 Hours
Accumulator Time accumulator counter for total hours of accumulated time. Hr 0…9999
