Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 245
PowerMonitor 5000 Unit Data Tables Appendix A
6 Int16 MID_Peak_PM_Hours This bit map selects any p.m. hours that are designated as MID Peak.
Bit0 = 12 p.m. to 1 p.m.
Bit1 = 1 p.m. to 2 p.m.
Bit2 = 2 p.m. to 3 p.m.
Bit 3 = 3 p.m. to 4 p.m.
…
Bit11 = 11 p.m. to 12 p.m.
Example: The hours from 3 p.m. to 7 p.m. is designated as Bit 3 through
Bit 6 = 120d. 120 0…4095
7 Int16 ON_Peak_AM_Hours This bit map selects any a.m. hours that are designated as ON Peak.
Bit0 = 12 a.m. to 1 a.m.
Bit1 = 1 a.m. to 2 a.m.
Bit2 = 2 a.m. to a.m.
Bit 3 = 3 a.m. to 4 a.m.
…
Bit11 = 11 a.m. to 12 a.m.
Example: The hours from 11 a.m. to 12 p.m. is designated as Bit 11 = 2048d. 2048 0…4095
8 Int16 ON_Peak_PM_Hours This bit map selects any p.m. hours that are designated as ON Peak.
Bit0 = 12 p.m. to 1 p.m.
Bit1 = 1 p.m. to 2 p.m.
Bit2 = 2 p.m. to 3 p.m.
Bit 3 = 3 p.m. to 4 p.m.
…
Bit11 = 11 p.m. to 12 p.m.
Example: The hours from 12 p.m. to 3 p.m. is designated as Bit 0 through Bit 2 = 7d
. 7 0…4095
9 Int16 Load_Factor_Auto_Log_Setting Automatically stores the current peak, average and load factor results as a record in
the the non volatile load factor log and resets the log at the specified day of the
month.
0 = Disable storing records
1 = Store and clear on the first day of the month
2 = 2nd of month
3 = 3rd day of month…to 31st day
If set to 29…31 the last day of every month stores a record. 31 0…31
10 Int16 PowerQuality_Log_Mode This parameter sets the action of the log once it has filled to capacity.
0 = Fill and Stop
1 = Overwrite oldest record 1 0…1
11 Int16 Event_Log_Mode This parameter sets the action of the log once it has filled to capacity.
0 = Fill and Stop
1 = Overwrite oldest record 1 0…1
12…39 Int16 Reserved 0 0
Table 52 - Configuration.Logging Data Table
Element
Number Type Tag Name Description Default Range
