Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 365
PowerMonitor 5000 Unit Data Tables Appendix A
Table 190 - PowerQuality.Harmonic Results Data Table template, H2 order range (32…63)
Element
Number Type Tag Name Description Units Range
0 Real Metering_Date_Stamp Date of cycle collection MMDDYY MM:DD:YY 0…123199
1 Real Metering_Time_Stamp Time of cycle collection hhmmss hhmmss 0…235959
2 Real Metering_Microsecond_Stamp Microsecond of cycle collection uS 0.000…999999
3 Real __h32__
The value of the specified harmonic component: RMS
magnitude or Angle Same as string
in Tag Name: kW kVAR
kVA Volts Amps 0…9.999E15
4 Real __h33__
0…9.999E15
5 Real __h34__
0…9.999E15
6 Real __h35__
0…9.999E15
7 Real __h36__
0…9.999E15
8 Real __h37__
0…9.999E15
9 Real __h38__
0…9.999E15
10 Real __h39__
0…9.999E15
11 Real __h40__
0…9.999E15
12 Real __h41__
0…9.999E15
13 Real __h42__
0…9.999E15
14 Real __h43__
0…9.999E15
15 Real __h44__
0…9.999E15
16 Real __h45__
0…9.999E15
17 Real __h46__
0…9.999E15
18 Real __h47__
0…9.999E15
19 Real __h48__
0…9.999E15
20 Real __h49__
0…9.999E15
21 Real __h50__
0…9.999E15
22 Real __h51__
0…9.999E15
23 Real __h52__
0…9.999E15
24 Real __h53__
0…9.999E15
