PowerMonitor 5000 Display Module Application
Summary

Introduction

The PowerMonitor 5000 Display Module, catalog number 1426-DM, is a
PanelView Component C400 terminal with factory-installed applications. This
display module displays key information from one, two, or three
PowerMonitor 5000 units. Minimal setup for communication is required.

Refer to the PanelView Component HMI Terminals User Manual, publication

2711C-UM001,

for additional information on performing the steps outlined in

this Appendix.

Terminal Setup

Follow these instructions for setting up the C400 terminal.

Obtain an IP address for the C400 terminal and set it as a static IP address
in the C400 terminal.

Open a compatible web browser and type the terminal IP address into the
address bar.

The PanelView Explorer Startup window appears.

Disable the web browser pop-up blocker, if necessary.

IMPORTANT

In order for the C400 terminal application to communicate with a power
monitor, both need their own unique IP address on the same network and
subnet. The computer you use for set-up must also access the same network.
