100 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Chapter 6 Logging
Logging Overview The PowerMonitor 5000 unit maintains a number of types of internal data logs
and records metering, status, event, and alarm data into these logs as specified in
the logging configuration. This table summarizes the data log types and sizes, and
how their records can be retrieved.
Setup
The following set-up parameters define the behavior of the data logging functions
in the PowerMonitor 5000 unit, except for the Data Log, which has its own set of
set-up parameters. These parameters are found in the
Configuration.Logging
table.
Energy_Log_Interval
Energy_Log_Interval selects how often a record is logged, in minutes:
0 = Disables energy logging
1…60 = Length of logging interval in minutes
-1 = Synchronizes energy logging to the end of the demand interval
Energy_Log_Mode
Energy_Log_Mode defines the log behavior when full:
0 = Stop logging
1 = Delete oldest energy log file and create a new file
Log Type Model Max Number of Records Log Data Retrieval Method
Read Selected
Record Read Records
Sequentially, in
Forward or
Reverse Order Web File
Download FTP File
Download
Waveform log M6 21,600 cycles, 256 files • • •
Energy log All 90 days (129,600 @ 1 minute log rate) • • •
Data log All 60,000 @ 32 parameters • • •
Min/Max log All 82 parameters • • • •
Load Factor log All 13 Including Current Month • • • •
Time-of-Use log All 13 Including Current Month • • • •
Alarm log All 100 Alarms • • •
Event log All 100 Events • • •
Setpoint log All 100 Setpoint Events • • •
Power Quality log M6 100 • • •
Trigger Data log M6 3,600 cycles, 60 files • • •
Snapshot log M6 2270 parameters 1 file • • •
