Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 3
Summary of Changes
This manual contains new and updated information. Changes throughout this
revision are marked by change bars, as shown to the right of this paragraph.
New and Updated
Information This table contains the changes made to this revision.
Topic Page
Added information about the M6 model. Throughout
Added information on connecting to a ControlNet network. 40
Added information on setting up ControlNet network communication. 47
Added information about Power Quality monitoring 74
Updated the Logging Overview section 99
Added information on Waveform Log 105
Added parameters to the Data Log Parameter list 114
Added parameters to the Alarm Codes and Description list 137
Added information about the Power Quality Log 141
Added information about the Trigger Data Log 145
Added information about the Snapshot Log 148
Added information about Setpoint Logic Gates 160
Added parameters to the Setpoint Output Action List 167
Added information about Optional ControlNet Communication 183
Added information about Electronic Data Sheet 184
Added ControlNet netwrok information Chapter 9
Added ControlNet I/O Connection information 208
Added information about Upgrading the PowerMonitor 5000 Model and Communication 223
Added data table information for the following:
• Configuration.Setpoints_11_15 (M6 model)
• Configuration.Setpoints_16_20 (M6 model)
• Configuration.Setpoint_Logic (M6 Model)
• Configuration.TriggerDataLogFile (M6 Model)
• Configuration.TriggerSetpointInfoFile (M6 model)
• Configuration.TriggerData(M6 model)
• Configuration.WaveformFileName (M6 model)
• Status.OptionalComm
• Status.IEEE1588 (M6 model)
• Statistics.Setpoint_Output
• Statistics.Logging
• Statistics.Setpoint_Logic (M6 model)
• LoggingResults. TriggerLog_Setpoint_Info_File_Name (M6 model)
• LoggingResults.TriggerLog_FileName (M6 model)
• LoggingResults.TriggerData_Header Data Table (M6 model)
• LoggingResults.TriggerData_Log (M6 model)
• LoggingResults.Power_Quality_Log (M6 model)
• LoggingResults.Snapshot_Log (M6 model)
• LoggingResults.WaveformFileName (M6 model)
• LoggingResults.Waveform_Log (M6 model)
• PowerQuality.Harmonics_Results (M6 model)
• PowerQuality.IEEE1159_Results (M6 model)
• PowerQuality.Synchro_Phasor_Results
• PowerQuality.IEEE519_ Results (M6 model)
• PowerQuality.Harmonics Results (M6 model) Appendix A
Removed reserved elements in Table 116 - Status.Alarms Data Table 302
Added information for PowerMonitor 5000 Waveform Capture and Compression (M6 model) Appendix D
