Rockwell Automation 1426 PowerMonitor 5000 Unit User Manual
Page 115
Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
115
Logging
Chapter 6
37
L2_PF_Lead_Lag_Indicator
%
38
L3_PF_Lead_Lag_Indicator
%
39
Total_PF_Lead_Lag_Indicator
%
40
V1_Crest_Factor
CF
41
V2_Crest_Factor
CF
42
V3_Crest_Factor
CF
43
V1_V2_Crest_Factor
CF
44
V2_V3_Crest_Factor
CF
45
V3_V1_Crest_Factor
CF
46
I1_Crest_Factor
CF
47
I2_Crest_Factor
CF
48
I3_Crest_Factor
CF
49
I4_Crest_Factor
CF
50
V1_IEEE_THD_%
%
51
V2_IEEE_THD_%
%
52
V3_IEEE_THD_%
%
53
VGN_IEEE_THD_%
%
54
Avg_IEEE_THD_V_%
%
55
V1_V2_IEEE_THD_%
%
56
V2_V3_IEEE_THD_%
%
57
V3_V1_IEEE_THD_%
%
58
Avg_IEEE_THD_V_V_%
%
59
I1_IEEE_THD_%
%
60
I2_IEEE_THD_%
%
61
I3_IEEE_THD_%
%
62
I4_IEEE_THD_%
%
63
Avg_IEEE_THD_I_%
%
64
V1_IEC_THD_%
%
65
V2_IEC_THD_%
%
66
V3_IEC_THD_%
%
67
VGN_IEC_THD_%
%
68
Avg_IEC_THD_V_%
%
69
V1_V2_IEC_THD_%
%
70
V2_V3_IEC_THD_%
%
71
V3_V1_IEC_THD_%
%
72
Avg_IEC_THD_V_V_%
%
73
I1_IEC_THD_%
%
74
I2_IEC_THD_%
%
75
I3_IEC_THD_%
%
Table 19 - Data Log Parameter List
Parameter
Number
Parameter Tag Name
Units
