236 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
100 2 INT R1PulseDuration Set as 50…1000 to indicate the duration of the pulse in milliseconds,
or set to 0 for KYZ-style transition output. (Toggle)
IMPORTANT: The value for delay is rounded off to the nearest 10 ms
internally during this function. Relay 1 Output
Duration 0 or 50…1000
2 INT Pad23 For alignment purpose
104 1 SINT R2OutputMode The parameter selected will pulse the relay 2 output at a rate that
equals the parameter value divided by relay 2 scale.
0 = Setpoint Control
1 = Wh Fwd
2 = Wh Rev
3 = VARh Fwd
4 = VARh Rev
5 = VAh
6 = Ah Relay 2 Output
Parameter 0…6
1 SINT Pad24 For alignment purpose
2 INT Pad25 For alignment purpose
108 4 DINT R2PulseScale The relay 2 output parameter divided by the relay 2 scale is the output
pulse rate. Example: Wh is selected for the parameter and 1,000 is the
scale value. The output is pulsed every kWh. Relay 2 Output
Scale 1…100,000
112 2 INT R2PulseDuration Set as 50…1000 to indicate the duration of the pulse in milliseconds,
or set to 0 for KYZ-style transition output. (Toggle)
IMPORTANT: The value for delay is rounded off to the nearest 10 ms
internally during this function. Relay 2 Output
Duration 0 or 50…1000
2 INT Pad26 For alignment purpose
116 1 SINT R2OutputMode The parameter selected will pulse the relay 3 output at a rate that
equals the parameter value divided by relay 3 scale.
0 = Setpoint Control
1 = Wh Fwd
2 = Wh Rev
3 = VARh Fwd
4 = VARh Rev
5 = VAh
6 = Ah Relay 3 Output
Parameter 0…6
1 SINT Pad27 For alignment purpose
2 INT Pad28 For alignment purpose
120 4 DINT R3PulseScale The relay 3 output parameter divided by the relay 3 scale is the output
pulse rate. Example: Wh is selected for the parameter and 1,000 is the
scale value. The output is pulsed every kWh. Relay 3 Output
Scale 1…100,000
124 4 INT R3PulseDuration Set as 50…1000 to indicate the duration of the pulse in milliseconds,
or set to 0 for KYZ-style transition output. (Toggle)
IMPORTANT: The value for delay is rounded off to the nearest 10 ms
internally during this function. Relay 3 Output
Duration 0 or 50…1000
2 INT Pad29 For alignment purpose
128 4 DINT S1ScaleFactor When a status pulse is received the count is increased by the scale
factor. (Input pulse * input scale) added to total status count. Status 1 Input
Scaling 1…1,000,000
132 4 DINT S2ScaleFactor When a status pulse is received the count is increased by the scale
factor. (Input pulse * input scale) added to total status count. Status 2 Input
Scaling 1…1,000,000
136 4 DINT S3ScaleFactor When a status pulse is received the count is increased by the scale
factor. (Input pulse * input scale) added to total status count. Status 3 Input
Scaling 1…1,000,000
140 4 DINT S4ScaleFactor When a status pulse is received the count is increased by the scale
factor. (Input pulse * input scale) added to total status count. Status 4 Input
Scaling 1…1,000,000
Table 44 - Configuration.Instance Data Table
Start
Byte Size Type Tag Name Description Units Range
