Rockwell Automation Publication 1426-UM001F-EN-P - November 2013 293
PowerMonitor 5000 Unit Data Tables Appendix A
Status.RunTime
Table 105 - Table Properties
CIP Instance Number 825
PCCC File Number N34
No. of Elements 86
Length in Words 86
Data Type Int16
Data Access Read Only
Table 106 - Status.RunTime Data Table
Element
Number Type Tag Name Description Range
0 Int16 Assembly_Slot_0_Status_inst_1 Backplane Processor (BF518) Status MPC
0 = Status PASS 0…65,535
Bit0 Nor Flash BF518 Nor flash read write failure
Bit1 SDRAM Memory BF518 SDRAM memory failure
Bit2 Ethernet MAC BF518 Ethernet MAC failure
Bit3 SPORT Interface BF518 SPORT communication failure
Bit4 ARM9 Heartbeat message Timeout ARM9 Heartbeat message Timeout
Bit5 Backplane info. message Timeout Backplane info. message Timeout
Bit6 Create Connection Message Not Received MPC BF518 did not receive create connection
Bit7 Backplane Connection Status Backplane connection status
0 = OK
1 = Fail
Bit8 SPORT HandShake Not Received MPC BF518 did not get ARM9 Handshake Signal
1 Int16 Assembly_Slot_0_Status_Inst_2 ARM Processor Status MPC
0 = Status PASS 0…65,535
Bit0 Nor Flash ARM9 Nor flash read write failure
Bit1 Nand Flash ARM9 Nand flash read write failure
Bit2 SDRAM Memory ARM9 SDRAM memory failure
Bit3 FRAM Memory ARM9 EEPROM storage failure
Bit4 Synchronous Serial Controller (SSC) ARM9 serial intercommunication failure
Bit5 Real Time Clock ARM9 Real time clock failure
Bit6 Ethernet MAC ARM9 Arm9 Ethernet MAC failure
Bit7 Anybus Interface ARM9 HMS Anybus interface failure
Bit8 SPI Serial Interface ARM9 SPI Intercommunications failure
Bit9 USB Memory Stick Failure ARM9 USB Memory Stick read write failure
Bit10 MPC BF518 Heartbeat message Timeout MPC BF518 Heartbeat message Timeout
Bit11 Create Connection Message Not Send ARM9 did not send create connection to MPC BF518
Bit12 SPORT HandShake Not Received ARM9 did not get MPC BF518 Handshake Signal
Bit13 No Production Test Data Production test data not programmed or corrupted
