Appendix A PowerMonitor 5000 Unit Data Tables
LoggingResults.Snapshot_Log (M6 model)
LoggingResults.WaveformFileName (M6 model)
18 Real Event_Duration_mS Event duration in millisecond for sag/swell event, Event duration in cycles for WSB events mS 0…60000
19 Real Min_or_Max_Volts Min value of sag event or Max value of swell event. Volts +/-
0…9.999e15
20 Real Trip_Point The trip point that triggered the event # +/-
0…9.999e15
21 Real WSB_Originator ID of the WSB message generator, the 3 least significant bytes of MAC ID. # 0…16777215
(0x0…0xFFFFFF)
22…31 Real Reserved Future Use 0
Table 170 - LoggingResults. Power_Quality_Log Data Table
Element
Number Type Tag Name Description Unit Range
Table 171 - Table Properties
CIP Instance Number 872
PCCC File Number F81
No. of Elements 2
Length in Words 4
Data Type Real
Data Access Read Only
Table 172 - LoggingResults. Snapshot_Log Data Table
Element
Number Type Tag Name Description Unit Range
0 Real Parameter_Number The number of the parameter from the metering snapshot parameter list. # 1…2270
1 Real Parameter_Value The value recorded when metering data snapshot 9.999E-15
…9.999E15
Table 173 - Table Properties
CIP Instance Number 869
PCCC File Number ST78
No. of Elements 1
Length in Words 32
Data Type String
Data Access Read Only
Table 174 - LoggingResults. WaveformFileName Data Table
Element
Number Type Tag Name Description Default Range
0 String Waveform_File_Name A single entry table for a 64 character Filename entry 0 64 bytes
