PowerMonitor 5000 Unit Data Tables
48
1
SINT
RealTimeUpdateRate
Selects the update rate for the realtime table and the setpoint
calculations.
0 = Single cycle averaged over 8 cycles
1 = Single cycle averaged over 4 cycles
2 = 1 cycle with no averaging
3 = 200 ms per EN61000-4-30 (M6 and M8 Only)
Meter
Averaging
0…3
1
SINT
Pad08
For alignment purpose
2
INT
Pad09
For alignment purpose
52
2
INT
DeviceFaultAction
This parameter determines the action when a unit error occurs.
0 = Halt on error and make status indicator solid red
1 = Reset power monitor hardware
Error Action
0…1
54
2
INT
EnergyLogInverval
Selects how often a record is logged (minutes). A value of 0 disables
periodic logging of records. A value of -1 causes the logging of records
to be synchronized to the end of the demand Interval.
Energy Interval
(Minutes)
-1…60
56
2
INT
EnergyLogMode
This parameter sets the action of the log once it has filled to capacity.
0 = Fill and Stop
1 = Overwrite oldest record.
Energy Log
Mode
0…1
58
2
INT
TOU AutoStoreDay
Automatically stores the current record for the month replacing an
older record if the log is full. The log holds 12 records plus the current
record.
0 = Disable storing records
1 = Store and clear on the first day of the month
2 = 2nd of month
3 = 3rd day of month
…
31 = 31st day of month
If set to 29…31 the last day of every month stores a record.
AutoStore
0…31
60
1
SINT
DemandSource
When item ‘Demand Broadcast Master Select’ of the Ethernet table is
set to a master selection of 0…2 sets the type of master input. In this
case item ‘3’ is ignored. When the ‘Demand Broadcast Master Select’
of the Ethernet table is set to slave, then any of these inputs can set
the end of the demand period.
0 = Internal Timer
1 = Status Input 2
2 = Controller Command
3 = Ethernet Demand Broadcast
Demand Period
Length
0…3
1
SINT
Pad10
For alignment purpose
2
INT
Pad11
For alignment purpose
64
1
SINT
DemandPeriodLength
Specifies the desired period for demand calculations. When set to 0
there is no projected demand calculations. If the internal timer is
selected a setting of 0 turns the demand function off.
Number
Demand
Periods
0…99
1
SINT
Pad12
For alignment purpose
2
INT
Pad13
For alignment purpose
68
1
SINT
NumberOfDemandCycles
Specifies the number of demand periods to average for demand
measurement.
Demand Sync
Delay
1…15
1
SINT
Pad14
For alignment purpose
2
INT
Pad15
For alignment purpose
Table 44 - Configuration.Instance Data Table
Start
Byte
Size Type
Tag
Name
Description
Units
Range
