Configuration.communications_native – Rockwell Automation 1426 PowerMonitor 5000 Unit User Manual
Page 251
Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
251
PowerMonitor 5000 Unit Data Tables
Appendix A
Configuration.Communications_Native
Table 57 - Table Properties
CIP Instance Number
804
PCCC File Number
N13
No. of Elements
70
Length in Words
70
Data Type
Int16
Data Access
Read/Write
Table 58 - Configuration.Communications_Native Data Table
Element
Number
Type
Tag Name
Description
Default
Range
0
Int16
IP_Address_Obtain
Selects the IP Address at startup
0 = Static IP
1 = DHCP
1
0…1
1
Int16
IP_Address_A
First Octet of Unit IP Address
192
0…255
2
Int16
IP_Address_B
Second Octet of Unit IP Address
168
0…255
3
Int16
IP_Address_C
Third Octet of Unit IP Address
1
0 …255
4
Int16
IP_Address_D
Fourth Octet of Unit IP Address
100
0…255
5
Int16
Subnet_Mask_A
First Octet of Subnet Mask
255
0…255
6
Int16
Subnet_Mask_B
Second Octet of Subnet Mask
255
0…255
7
Int16
Subnet_Mask_C
Third Octet of Subnet Mask
255
0…255
8
Int16
Subnet_Mask_D
Fourth Octet of Subnet Mask
0
0…255
9
Int16
Gateway_Address_A
First Octet of Gateway Address
192
0…255
10
Int16
Gateway_Address_B
Second Octet of Gateway Address
168
0…255
11
Int16
Gateway_Address_C
Third Octet of Gateway Address
1
0…255
12
Int16
Gateway_Address_D
Fourth Octet of Gateway Address
1
0…255
13
Int16
DNS_Enable
Selects DNS Option 0 = Disable, 1 = Enable
0
0…1
14
Int16
DNS_Server_Address_A
First Octet of DNS Server Address
0
0…255
15
Int16
DNS_Server_Address_B
Second Octet of DNS Server Address
0
0…255
16
Int16
DNS_Server_Address_C
Third Octet of DNS Server Address
0
0…255
17
Int16
DNS_Server_Address_D
Fourth Octet of DNS Server Address
0
0…255
18
Int16
DNS_Server2_Address_A
First Octet of DNS Server Address
0
0 …255
19
Int16
DNS_Server2_Address_B
Second Octet of DNS Server Address
0
0 …255
20
Int16
DNS_Server2_Address_C
Third Octet of DNS Server Address
0
0…255
21
Int16
DNS_Server2_Address_D
Fourth Octet of DNS Server Address
0
0…255
22
Int16
Time_Sync_Source
Selection for Time Sync
0 = Disable
1 = SNTP
2 = PTP (IEEE1588)
2
0…2
