242 Rockwell Automation Publication 1426-UM001F-EN-P - November 2013
Appendix A PowerMonitor 5000 Unit Data Tables
123 Status_1_Count_xM Real xM Status 1 Count times 1,000,000
124 Status_1_Count_x1 Real x1 Status 1 count times 1
125 Status_2_Count_xM Real xM Status 2 Count times 1,000,000
126 Status_2_Count_x1 Real x1 Status 2 count times 1
127 Status_3_Count_xM Real xM Status 3 Count times 1,000,000
128 Status_3_Count_x1 Real x1 Status 3 count times 1
129 Status_4_Count_xM Real xM Status 4 Count times 1,000,000
130 Status_4_Count_x1 Real x1 Status 4 count times 1
131 GWh_Fwd Real GWh Forward gigawatt hours
132 kWh_Fwd Real kWh Forward kilowatt hours
133 GWh_Rev Real GWh Reverse gigawatt hours
134 kWh_Rev Real kWh Reverse kilowatt hours
135 GWh_Net Real GWh Net gigawatt hours
136 kWh_Net Real kWh Net kilowatt hours
137 GVARH_Fwd Real GVARh Forward gigaVAR hours
138 kVARh_Fwd Real kVARh Forward kiloVAR hours
139 GVARH_Rev Real GVARh Reverse gigaVAR hours
140 kVARh_Rev Real kVARh Reverse kiloVAR hours
141 GVARH_Net Real GVARh Net gigaVAR hours
142 kVARh_Net Real kVARh Net kiloVAR hours
143 GVAh Real GVAh Net gigaVA hours
144 kVAh Real kVAh Net kiloVA hours
145 GAh Real GAh Net giga Amp hours
146 kAh Real kAh Net kilo Amp hours
147 kW_Demand Real kW The average real power during the last demand period
148 kVAR_Demand Real kVAR The average reactive power during the last demand period
149 kVA_Demand Real kVA The average apparent power during the last demand period
150 Demand_PF Real PF The average PF during the last demand period
151 Demand_Amperes Real A The average demand for amperes during the last demand period
152 Projected_kW_Demand Real kW The projected total real power for the current demand period
153 Projected_kVAR_Demand Real kVAR The projected total reactive power for the current demand period
154 Projected_kVA_Demand Real kVA The projected total apparent power for the current demand period
155 Projected_Ampere_Demand Real A The projected total amperes for the current demand period
156 Elapsed_Demand_Period_Time Real Min The amount of time that has elapsed during the current demand period
157 I1_K_Factor Real KF I1 K-factor
158 I2_K_Factor Real KF I2 K-factor
159 I3_K_Factor Real KF I3 K-factor
160 IEEE_519_TDD_% Real % Total Demand Distortion used for IEEE 519 Pass/Fail Status
161 Setpoints_1_10_Active Int16 N/A Actuation Status of Setpoints 1…10
Table 48 - Display Parameter Object Table
Instance
Number Parameter Object Name Type Units Description
